Semi-Hermetic Refrigeration Scroll Compressor

YSF
series for Lower
temperature application



InvoTech YH series Scroll Compressors

Specific Design For A/C and Chiller, Not Only The Scroll Set But Also The Unit, Precise Product-Definition Based On Customer's Need

  • Both Build-in Radius and Axial Compliance Design, Improved Floating Seal Design for Better Energy Efficiency
  • Excellent Discharge Temperature Management to Stretch Operation Envelope
  • Accurate Calculation of Load and Sealing Force for Running Sound Optimization
  • High Efficiency Motor Design


Build-in Sound Insulation Internal Pressure Relief Valve Scroll Set Specially Design for A/C and Chiller Application Pilot Ring Main Bearing Housing Floating Seal Unloader Bush Build-in Motor Protector High Efficiency Motor Optimized For A/C and Chiller Lower Bearing Plate

Features

  • Build-in Sound Insulation to Reduce Running Sound
  • Optimized Design Compression Ratio for A/C and Chiller Application
  • Optimized Floating Seal Design for Better COP
  • Multiple Internal Protections
  • High Pressure Protection
  • Overload Protection
Y H 150 A 1 G - V 10 0 Product Type Capacity at Rating Point, 50Hz: X 100 Watt 1 - 3ph/380-420V/50Hz or 3ph/460V/60Hz2 - 1ph/220V/50Hz 3 - 1ph/220V/60Hz 5 - 3ph/380V/60Hz6 - 3ph/220V/50Hz7 - 3ph/220V/60Hz8 - 3ph/575V/60Hz H - A / C & Chiller M - Mid. Temp. F - Low Temp. W - Heat Pump Application Default - None V - Vapor Injection Q - Liquid Injection Model Code Engineering Code Accessory Code Default - None G - Side Glass and Soldering Connection S - Side Glass and Screw Connection A - R22 or Other Refrigerants Application in 3GS OilC - R410AE - R404A or Other Refrigerants Application in POE OilJ - R134aT - R407C or Other Refrigerants Application in POE Oil Remarks: Pls Confirm with InvoTech for Refrigerants that Not Been Involved.
DWM Copeland Panasonic (Sanyo) Danfoss InvoTech
R407C                                                                                                          380/415V-3Ph-50Hz        440/460V-3Ph-60Hz
Model c.c. HP KW Model c.c. HP KW Model c.c. HP KW Model c.c. HP KW
ZR28K3E-TFD 39,08 2,00 6,65                 YH69T1-100 38,10 2,00 6,53
ZR36K3E-TFD 48,68 3,00 8,45         HRP038T4 51,60 3,20 8,84 YH89T1-100 49,00 3,00 8,50
ZR42K3E-TFD 56,72 3,50 9,75 C-SBN263H8A 55,70 3,50 9,60 HRP042T4 57,20 3,50 9,58 YH104T1-100 59,00 3,50 10,20
ZR48K3E-TFD 65,52 4,00 11,40 C-SBN303H8G 66,80 4,00 11,60 HRP048T4 64,40 4,00 11,10 YH119T1-100 65,70 4,00 11,40
ZR52K3E-TFD 72,58 4,00 12,35         HRP051T4 68,80 4,30 12,13 YH128T1-100 71,00 4,00 12,40
ZR54KCE-TFD 75,37 4,50 12,40         HRP054T4 72,80 4,50 12,70 YH133T1-100 73,80 4,50 12,70
ZR57KCE-TFD 77,33 4,60 13,10 C-SBN353H8G 77,40 4,60 13,40 HRP058T4 78,20 4,80 13,48 YH140T1-100 77,10 4,60 13,30
ZR61KCE-TFD 82,76 5,00 14,30 C-SBN373H8G 83,20 5,00 14,50 HRP060T4 81,00 5,00 13,86 YH150T1-100 82,90 5,00 14,40
ZR72KCE-TFD 98,28 6,00 16,60 C-SBN453H8G 100,00 6,00 17,60 HLP072T4 98,70 6,00 16,62 YH175T1-100 96,70 6,00 16,80
                HLP075T4 102,80 6,30 18,04 YH190T1-100 104,02 6,50 18,05
ZR81KCE-TFD 108,05 7,00 18,60 C-SBS235H38B 110,20 7,00 19,50 HLP081T4 110,90 6,80 19,49 YH200T1-100 106,70 7,00 19,20
ZR94KCE-TFD 127,01 8,00 23,00 C-SCN583H8H 131,90 8,00 23,60 HCP094T4 126,00 8,00 21,59 YH230T1-100 122,30 8,00 22,10
        C-SCN603H8H 137,00 8,00 24,50
ZR108KCE-TFD 143,10 9,00 25,80 C-SCN673H8H 148,80 9,00 26,50 HCP109T4 148,80 9,00 26,06 YH266T1-100 141,10 9,00 25,50
ZR125KCE-TFD 167,24 10,00 30,20 C-SCN753H8H 171,20 10,00 29,90 HCP120T4 162,40 10,00 28,15 YH307T1-100 166,30 10,00 29,50
ZR144KCE-TFD 190,80 12,00 34,60 C-SCN903H8H 205,40 12,00 34,90 SZ148-4 199,00 12,00 35,I2 YH355T1-100 188,00 12,00 34,10
ZR160KCE-TFD 209,19 13,00 37,50         SZ161-4 216,60 10,00 38,0I YSH400T1G-100 216,67 13,00 38,98
ZR190KCE-TFD 248,84 15,00 44,00         SZ185-4 249,90 12,00 43,11 YSH450T1G-100 244,25 15,00 43,97
Operation Conditions ARI +7.2°C +54.4°C


DWM Copeland Panasonic (Sanyo) Danfoss InvoTech
R410A                                                                                                         380/415V-3Ph-50Hz        440/460V-3Ph-60Hz
Model c.c. HP KW Model c.c. HP KW Model c.c. HP KW Model c.c. HP KW
ZP36KSE-TFMN 34,48 3,00 8,92 C-SBP120H38A 39,90 3,50 10,00 HRH038U4 36,50 3,20 9,25 YH95C1-100 38,30 3,50 9,50
ZP49K5E-TFD 46,93 4,00 11,95 C-SBP140H38A 46,40 4,00 11,70 HRH049U4 47,40 4,10 12,11 YH119C1-100 45,70 4,00 11,90
ZP54KSE-TFMN 51,15 4,50 12,95 C-SBP160H38A 51,80 4,60 13,20 HRH051U4 49,30 4,30 12,86 YH128C1-100 49,10 4,50 12,80
ZP61KCE-TFD 58,05 5,00 14,70 C-SBP170H38A 55,70 5,00 14,20 HLH061T4 57,80 5,10 15,21 YH150C1-100 58,90 5,00 15,00
ZP72KCE-TFD 67,24 6,00 17,15 C-SBP205H38A 66,80 6,00 16,80 HLH072T4 68,00 6,00 17,84 YH175C1-100 65,70 6,00 17,30
ZP76KCE-TFD 70,98 6,50 18,35         HLH075T4 70,80 6,30 18,60 YH183C1-100 70,90 6,50 18,30
ZP90KCE-TFD 83,91 8,00 21,80 C-SCP270H38A 89,20 8,00 22,40 HCJ090T4 86,90 7,50 22,32 YH230C1-100 90,30 8,00 23,00
ZP103KCE-TFD 96,55 9,00 25,20 C-SCP315H38A 104,10 10,00 26,00 HCJ105T4 101,60 8,80 26,10 YH266C1-100 99,40 9,00 26,60
ZP122KCE-TFD 112,07 10,00 30,00                 YH292C1-100 106,90 10,00 29,20
ZP137KCE-TFD 127,01 11,00 32,60 C-SCP360H38A 120,20 11,00 29,80 HCJ120T4 116,40 10,00 29,61 YH325C1-100 122,30 11,00 32,50
ZP144KCE-TFD 133,50 12,00 35,50 C-SCP400H38A 127,80 12,00 32,20 SH140-4 133,00 12,00 34,70 YH355C1-100 131,61 12,00 34,80
Operation Conditions ARI +7.2°C +54.4°C







InvoTech YM/YF series

Scroll Compressors With Dual-Compliance For Mid. Temp. Application

  • Specific Design for Refs. Application, Not Only the Scroll Set But Also the Unit, Precise Product-Definition
  • Based on Customer's Need
  • Both Build-in Radius and Axial Compliances Design, Improved Floating Seal Design for Better Energy Efficiency
  • Excellent Discharge Temperature Management to Stretch Operation Envelope
  • Accurate Calculation of Load and Sealing Force for Running Sound Optimization
  • High Efficiency Motor Design


Build-in Sound Insulation Internal Pressure Relief Valve Scroll Set Specially Design for Mid-Temp. Application Pilot Ring Main Bearing Housing Patented High Efficiency Discharge Valve Discharge Tube Floating Seal Unloader Bush Build-in Motor Protector High Efficiency Motor Optimized For Mid-Temp. Application Oil Glass

Features

  • Be Capable of Running Perfectly at as low as -15°C Evap. Temp. Without Liquid / Vapor Injection
  • 15% Better in terms of COP Than Similar Products in The Market
  • Build-in Sound Insulation to Reduce Running Sound
  • Scroll Design of Higher Build-in Compression Ratio For Refs. Application
  • Optimized Floating Seal Design for Better COP
  • Multiple Internal Protections
  • High Pressure Protection
  • Overload Protection

Scroll Compressors With Dual-Compliance For Low. Temp. Application

  • Specific Design for Refs. Application, Not Only the Scroll Set But Also the Unit, Precise Product-Definition
  • Based on Customer's Need
  • Both Build-in Radius and Axial Compliances Design, Improved Floating Seal Design for Better Energy Efficiency
  • Excellent Discharge Temperature Management to Stretch Operation Envelope
  • Accurate Calculation of Load and Sealing Force for Running Sound Optimization
  • High Efficiency Motor Design


Build-in Sound Insulation Internal Pressure Relief Valve Discharge Temperature Control Valve Scroll Set Specially Designed for Refs. Application Pilot Ring Main Bearing Housing Temperature Sensor Discharge Tueb Suction Tube Unloader Bush High Efficiency Motor Optimized For Refs. Application Oil Glass Build-in Motor Protector

Features

  • Be Capable of Running Perfectly at as low as -40°C Evap. Temp.
  • 20% Better in Terms of COP Than Similar Products in The Market
  • Build-in Sound Insulation to Reduce Running Sound
  • Truly Specific Scroll Design For Refs. Application
  • Optimized Floating Seal Design for Better COP
  • Multiple Internal Protections
  • High Pressure Protection
  • Overload Protection
DWM Copeland Panasonic (Sanyo) Danfoss InvoTech
R404A  MHBP                                                                                             380/415V-3Ph-50Hz        440/460V-3Ph-60Hz
Model c.c. HP KW Model c.c. HP KW Model c.c. HP KW Model c.c. HP KW
ZB15KCE-TFD 33,91 2,00 3,44         MLZ015T4   2,00 3,24 YM34E1G-100 33,30 2,00 3,47
ZB19KCE-TFD 39,08 2,50 4,08         MLZ019T4 43,50 2,50 4,39 YM43E1G-100 41,90 2,50 4,38
ZB21KCE-TFD 49,43 3,00 5,26         MLZ021T4 46,20 3,00 4,66 YM49E1G-100 46,20 3,00 5,00
ZB30KCE-TFD 67,24 4,00 7,17 C-SBN303L8A 66,80 4,00 5,30 MLZ030T4 68,80 4,00 7,03 YM70E1G-100 67,60 4,00 7,14
ZB38KCE-TFD 82,76 5,00 8,91 C-SBN373L8A 83,20 5,00 6,80 MLZ038T4 81,00 5,00 8,34 YM86E1G-100 82,90 5,00 8,75
ZB45KCE-TFD 98,28 6,00 10,50 C-SBN453L8A 104,00 6,00 8,10 MLZ045T4 98,60 6,00 10,03 YM102E1G-100 97,60 6,00 10,38
ZB50KCE-TFD 117,79 7,00 12,50         MLZ048T4 107,50 7,00 10,94 YM125E1G-100 114,90 7,00 12,75
ZB58KCE-TFD 127,01 8,00 13,95         MLZ058T4 126,00 7,50 12,88 YM132E1G-100 122,30 8,00 13,43
ZB66KCE-TFD 143,10 9,00 15,75         MLZ066T4 148,80 9,00 14,97 YM158E1G-100 144,60 9,00 16,10
ZB76KCE-TFD 167,24 10,00 18,65         MLZ076T4 162,40 10,00 16,73 YM182E1G-100 166,30 10,00 18,60
                        YM200E1G-100 188,00 12,00 20,35
                        YM210E1G-100 196,00 12,00 21,40
ZB95KCE-TFD 209,20 13,00 22,70                 YSM235E1G-100 216,67 13,00 23,22
ZB114KCE-TFD 248,84 15,00 27,00                 YSM260E1G-100 244,25 15,00 25,69
Operation Conditions ARI -6.7°C +48.9°C Operation Conditions ARI -15°C +50°C Operation Conditions ARI -6.7°C +48.9°C Operation Conditions ARI -6.7°C +48.9°C


DWM Copeland Panasonic (Sanyo) Danfoss InvoTech
R404A  LBP                                                                                                380/415V-3Ph-50Hz        440/460V-3Ph-60Hz
Model c.c. HP KW Model c.c. HP KW Model c.c. HP KW Model c.c. HP KW
ZF06K4E-TFD 33,91 2,00 1,63                 YF13E1G-Q100 33,30 2,00 1,54
ZF08K4E-TFD 41,95 2,50 2,03                 YF17E1G-Q100 41,90 2,50 1,97
ZF09K4E-TFD 45,98 3,00 2,23         LLZ013T4 46,20 3,00 2,84 YF20E1G-Q100 46,20 3,00 2,33
ZF13K4E-TFD 67,82 4,00 3,19 C-SBN303L8A 66,80 4,00 5,30 LLZ015T4 68,80 4,00 3,44 YF29E1G-Q100 67,60 4,00 3,42
ZF15K4E-TFD 83,33 5,00 3,92 C-SBN373L8A 83,20 5,00 6,80         YF35E1G-Q100 82,90 5,00 3,70
ZF18K4E-TFD 98,28 6,00 4,78 C-SBN453L8A 104,00 6,00 8,10 LLZ018T4 98,60 6,00 4,05 YF41E1G-Q100 97,60 6,00 4,30
Operation Conditions ARI -31.6°C +40.6°C Operation Conditions ARI -15°C +50°C Operation Conditions ARI -31.6°C +40.6°C Operation Conditions ARI -31.6°C +40.6°C



DWM Copeland Panasonic (Sanyo) Bitzer InvoTech
R404A  LBP                                                                                                380/415V-3Ph-50Hz        440/460V-3Ph-60Hz
Model c.c. HP KW Model c.c. HP KW Model c.c. HP KW Model c.c. HP KW
ZF18KVE-TFDEVI 98,28 6,00 6,84 C-SCN523L8H 120,00 7,00 9,25 4CES-6Y-40S 32,48 6,00 6,42 YSF60E1G-V100 115,50 7,00 6,91
        C-SCN603L8H 137,00 6,00 10,50 4TES-9Y-40P 41,33 9,00 7,79 YSF65E1G-V100 123,00 8,00 7,36
ZF25K5E-TFDEVI 122,99 8,00 8,73         4PES-12Y-40P 48,50 12,00 8,49 YSF75E1G-V100 145,40 9,00 8,70
ZF34K5E-TFDEVI 167,24 10,00 11,70 C-SCN753L8H 171,20 10,00 13,05 4NES-14Y-40P 56,25 14,00 10,60 YSF85E1G-V100 167,20 10,00 10,01
                        YSF90E1G-V100 189,10 12,00 11,32
ZF41K5E-TFDEVI 202,87 13,00 14,10         4JE-15Y-40P 63,50 15,00 12,77 YSF100E1G-V100 197,10 13,00 11,80
ZF49K5E-TFDEVI 243,67 15,00 15,95         4HE-18Y-40P 73,60 18,00 15,31 YSF125E1G-V100 248,28 15,00 14,60
Operation Conditions ARI -31.6°C +40.6°C Operation Conditions ARI -15°C +50°C Operation Conditions ARI -31.6°C +40.6°C Operation Conditions ARI -31.6°C +40.6°C





InvoTech YW series Scroll Compressors

Scroll Compressors With Dual-Compliance For Heat Pump Water Heater

  • Specific Design For Heat Pump Water Heater, Not Only The Scroll Set But Also The Unit, Precise Product-Definition
  • Based On Customer's Need
  • Both Build-in Radius and Axial Compliance Design, Improved Floating Seal Design for Better Energy Efficiency
  • Excellent Discharge Temperature Management to Stretch Operation Envelope
  • Accurate Calculation of Load and Sealing Force for Running Sound Optimization
  • High Efficiency Motor Design

Build-in Sound Insulation Internal Pressure Relief Valve Scroll Set Specially Design for HPWH Application Pilot Ring Main Bearing Housing Patented High Efficiency Discharge Valve Floating Seal Unloader Bush Build-in Motor Protector High Efficiency Motor Optimized For HPWH Application Lower Bearing Plate

Features

  • Be Capable of Running Perfectly at as low as -20°C Evap. Temp. Without
  • Any Extra Cooling to Discharge Gas
  • Build-in Sound Insulation to Reduce Running Sound
  • Truly Specific Scroll Design For Heat Pump Water Heater Application
  • Optimized Floating Seal Design for Better COP
  • Multiple Internal Protections
  • High Pressure Protection
  • Overload Protection


DWM Copeland Danfoss InvoTech
R407C                                                              380/415V-3Ph-50Hz        440/460V-3Ph-60Hz
Model c.c. HP KW Model c.c. HP KW Model c.c. HP KW
ZH21K4E-TFD 45,98 3,00 7,30 HHP021T4LP6 46,00 3,00 7,17 YW75T1-100 46,55 3,00 7,26
ZH30K4E-TFD 67,24 4,00 10,65 HHP030T4LC6 67,00 4,00 10,76 YW110T1-100 67,82 4,00 10,75
ZH38K4E-TFD 82,76 5,00 13,20 HHP038T4LC6 82,00 5,00 13,41 YW135T1-100 83,33 5,00 12,97
ZH45K4E-TWD 98,28 6,00 15,90 HHP045T4LC6 99,00 6,00 15,40 YW160T1-100 98,27 6,00 15,16
                YW190T1-100 115,52 7,00 18,62
ZH56K4E-TWD 120,11 8,00 19,40         YW205T1-100 122,99 8,00 19,74
                YW245T1-100 145,40 9,00 23,52
ZH75K4E-TWD 165,52 10,00 27,20         YW285T1-100 167,24 10,00 27,36
ZH92K4E-TWD 204,60 13,00 34,70         YW320T1-100 189,08 12,00 30,72
Operation Conditions ARI +5°C +55°C Operation Conditions ARI +5°C +55°C Operation Conditions ARI +5°C +55°C


DWM Copeland Danfoss InvoTech
R134a                                                              380/415V-3Ph-50Hz        440/460V-3Ph-60Hz
Model c.c. HP KW Model c.c. HP KW Model c.c. HP KW
ZH21K4E-TFD 45,98 3,00 5,55         YW55J1-100 46,55 3,00 5,51
ZH30K4E-TFD 67,24 4,00 8,04         YW80J1-100 67,82 4,00 8,00
ZH38K4E-TFD 82,76 5,00 9,89         YW100J1-100 83,33 5,00 9,35
ZH45K4E-TWD 98,28 6,00 11,95         YW120J1-100 98,27 6,00 11,59
                YW140J1-100 115,52 7,00 13,50
ZH56K4E-TWD 120,11 8,00 14,45         YW155J1-100 122,99 8,00 14,50
                YW180J1-100 145,40 9,00 17,00
ZH75K4E-TWD 165,52 10,00 20,10         YW200J1-100 1 67,24 10,00 19,60
ZH92K4E-TWD 204,60 13,00 25,50         YW240J1-100 189,08 12,00 23,98
Operation Conditions ARI +7.2°C +54.4°C   Operation Conditions ARI +7.2°C +54.4°C


DWM Copeland Danfoss InvoTech
R410A                                                              380/415V-3Ph-50Hz        440/460V-3Ph-60Hz
Model c.c. HP KW Model c.c. HP KW Model c.c. HP KW
ZH06K1P-TFM 29.31 3.00 6.97         YW75C1-100 33.33 3.00 7.8
ZH09K1P-TFM 39.66 4.00 9.45         YW110C1-100 46.55 4.00 10.7
ZH12K1P-TFM 51.15 5.00 12.10         YW135C1-100 59.2 5.00 13.7
ZH15K1P-TFM 67.24 6.00 15.95         YW160C1-100 67.82 6.00 15.8
                YW270C1-100 1 15.52 10.00 27.5
                YW320C1-100 131.61 12.00 31,50
Operation Conditions ARI +5°C +55°C   Operation Conditions ARI +5°C +55°C


InvoTech YSF series

Semi-Hermetic Refrigeration Scroll Compressor

  • Specific Design for Refs. Application, Not Only the Scroll Set But Also the Unit, Precise Product-Definition Based on Customer's Need
  • Both Build-in Radius and Axial Compliances Design, Improved Floating Seal Design for Better Energy Efficiency
  • Excellent Discharge Temperature Management to Stretch Operation Envelope
  • Accurate Calculation of Load and Sealing Force for Running Sound Optimization
  • High Efficiency Motor Design
  • Integrated Vapor Injection and Controller
  • Evaporating Temperature can be Lower to -40ºC

Discharge Temperature Sensor Service Valve - Discharge Service Valve - Suction Terminal Box Oil Sight Glass Crankcase Heater 75W Oil Drain with Schrader Valve Power Line InletCurrent Transformer (Only for Enhanced Type Controll Board) EVI Control Board EVI PHE Liquid Outlet EVI EXV Temperature Sensor after EXV Liquid Inlet Temperature Sensor after PHE EVI Vapor Inlet Bolt Holes for Threaded Flange of Oil Controller

DWM Copeland Panasonic (Sanyo) Bitzer InvoTech
R404A  LBP                                                                                                380/415V-3Ph-50Hz        440/460V-3Ph-60Hz
Model c.c. HP KW Model c.c. HP KW Model c.c. HP KW Model c.c. HP KW
ZF18KVE-TFDEVI 98,28 6,00 6,84 C-SCN523L8H 120,00 7,00 9,25 4CES-6Y-40S 32,48 6,00 6,42 YSF60E1G-V100 115,50 7,00 6,91
        C-SCN603L8H 137,00 6,00 10,50 4TES-9Y-40P 41,33 9,00 7,79 YSF65E1G-V100 123,00 8,00 7,36
ZF25K5E-TFDEVI 122,99 8,00 8,73         4PES-12Y-40P 48,50 12,00 8,49 YSF75E1G-V100 145,40 9,00 8,70
ZF34K5E-TFDEVI 167,24 10,00 11,70 C-SCN753L8H 171,20 10,00 13,05 4NES-14Y-40P 56,25 14,00 10,60 YSF85E1G-V100 167,20 10,00 10,01
                        YSF90E1G-V100 189,10 12,00 11,32
ZF41K5E-TFDEVI 202,87 13,00 14,10         4JE-15Y-40P 63,50 15,00 12,77 YSF100E1G-V100 197,10 13,00 11,80
ZF49K5E-TFDEVI 243,67 15,00 15,95         4HE-18Y-40P 73,60 18,00 15,31 YSF125E1G-V100 248,28 15,00 14,60
Operation Conditions ARI -31.6°C +40.6°C Operation Conditions ARI -15°C +50°C Operation Conditions ARI -31.6°C +40.6°C Operation Conditions ARI -31.6°C +40.6°C
